Residual current circuit breaker.
Features:Code: IDP.
No. of poles: 4P.
No. modules: 4.
Rated current: 40 A.
Rated residual operating current: 30 mA.
Type A.
Rated voltage (EN/IEC 61008-1, 61008-2-1): 400/415 V.
Standard: IEC/EN 61008-1, IEC/EN 61008-2-1.
Rated frequency (Hz): 50/60 Hz.
Insulation voltage: 500 V.
Rated impulse withstand voltage: 4 kV.
Overvoltage category: III.
Level of immunity (8/20 μs): 250 A.
Section rigid cable: <=1x35 - <=2x16 - <=1x16+2x10 mm².
Section flexible cable: <=1x35 - <=2x16 - <=1x16+2x10 mm².
Rated tightening torque: 3 Nm.
Double connection: Yes (up stream and down stram).
Operating temperature: -25 +60 °C.
Stocking temperature: -40 +70 °C.
Electrical endurance: ≥ 10000.
Mechanical endurance: ≥ 20000.
Auxiliaries compatibility: Yes.
ReStart compatibility: Yes.
Assembly position: Any.
