SL2.15 - SL Bass Enclosure

SL2.15 - SL Bass Enclosure
12611.56 Lei
*pretul include TVA
La comanda
KV2 Audio
cod produs: KVV 987 274
Descrierea Produsului
  • Slim, discreetly profiled wall mount cabinet
  • 129dB sustained output, 132dB peak with very high dynamic range
  • Simple wall mounting, suspension, ground stacking, or internally into walls and surfaces
  • These units can be designed and supplied with custom colors, grill templates and logos, offering a flexible and true designer integration product
  • A single horizontal yoke assembly with multiple fixed angle and fixing locations, provides a quick and cost effective solution for simple suspension options
  • Front-loaded, 2x 15-inch bass drivers with 3.00” voice coil assembly and ferrite magnetic motor structure
  • Professional, exterior-grade Baltic birch construction with wear-resistant polymer coating
  • Proprietary side handle designs for simplified handling and carrying
  • Internal back braces with nine M10 suspension points
  • A total of 23 suspension points are available for custom installation applications
  • Two SL2.15 speakers requires one channel of two channel VHD3200 subwoofer amplifier unit
  • The SL412i & SL2.15i are exact identical performance and finish units of the existing SL412 & SL2.15, except they do not incorporate the fixed handles for touring and presentation use. The ‘I’ version is designated for fixed installation use with the same existing mounting and flyware fixings.

System Acoustic Perfomance

Max SPL Long-term 129dB
Max SPL Peak 132dB
-3dB Response 40Hz ÷ 500Hz
-10dB Response 35Hz ÷ 500Hz
Sensitivity 100dB
Crossover Point 100÷500Hz

Low Frequency Section

Acoustic Design Direct-Radiating with Bass Reflex
Subwoofer Amplifier Requirement 1600W /2x SL2.15 (VHD3200 amp.)
Number of Drivers 2
Woofer Size / Voice Coil Diameter / Design 2x 15" / 3" Inside Outside
Diaphragm Material Epoxy Reinforced Cellulose
Magnet Type Ferrite

Speaker Input

Speaker Input EP4

Speaker Output

Speaker Output EP4


Cabinet Material 15mm Baltic birch
Handles 2
Color "Orange peeled" Matt Black or any RAL
