LD Systems VIBZ 12 DC - 12 Channel Mixing Console with DFX and Compressor

LD Systems VIBZ 12 DC - 12 Channel Mixing Console with DFX and Compressor
1627.84 Lei
1139.49 Lei
*pretul include TVA
In Stoc
LD Systems
cod produs: LDVIBZ12DC
Descrierea Produsului

The VIBZ 12 is a versatile mixer with six balanced microphone inputs featuring high quality preamplifiers, a low-cut filter, an effective 3-band EQ with conveniently selected mids and switchable phantom power.

Four microphone channels can be processed separately using the built-in compressor for an effective control of dynamics; two more can alternatively be used as a stereo line channels. The other stereo channels are equipped with 2-band EQs.

The master section of the mixer includes two effects loops, balanced XLR outputs, group and monitor outputs and a headphone jack. The VIBZ 12 also has RCA connectors for recording and playback devices and a digital Digital Effects Section with 100 presets.

With key features such as the PFL function or the Mute buttons and its natural, transparent sound, the VIBZ 12 is the perfect choice for live performances, installations and demanding home recording applications.

  • 12-channel mixer with 6 microphone channels
  • 4 stereo line inputs
  • Effective 3-band EQ
  • 2 stereo channels with 2-band EQ
  • Sliding adjustable compressor
  • Digital Effects Section with 100 Presets
  • Master, Monitor, Groups and headphone outputs
  • Built in power supply
Product typeMixers
TypeLive
Channels12

Mono Channels:

Mono Mic and Line Input Channels4
Mono Mic input connectors6.3 mm TRS, XLR
Mono Mic Input Typeelectronically balanced
Mono Mic Input Frequency Range10 - 45000 Hz
Amplification Range mono Mic Input0 - 50 dB
Mono Mic Input Input THD-N0.0058%
Mono Mic Input Impedance4k Ohm(s)
Mono Mic Input S/N Ratio113 dB
Mono Line Input Typeelectronically balanced
Mono Line Input Frequency Range10 - 45000 Hz
Amplification Range mono Line Input0 - 50 dB
Mono Line Input Input THD-N0.0045 %
Mono Line Input Impedance21k Ohm(s)
Mono Line Input S/N Ratio116 dB
Mono Channel Equalizer High+/- 15 dB @ 12000 Hz
Mono Channel Equalizer Mid+/- 15 dB @ 2,500 Hz
Mono Channel Equalizer Low+/- 15 dB @ 80 Hz
Controls Mono Mic and Line Input Channels3-band EQ (High, Mid, Low), AUX 1 umschaltbar Pre/Post, AUX 2 (DFX) Post, Compressor, DFX/AUX 1, Gain, Low Cut (75 Hz), PFL
Phantom power48 V DC switchable

Stereo Channels:

Stereo Line Input Channels4
Stereo Line Input Connectors6.3 mm TRS, RCA
Stereo Line Input Typeelectronically balanced, unbalanced
Stereo Line Input Frequency Range10 - 45000 Hz
Amplification Range stereo Line Input0 - 50 dB
Stereo Line Input Input THD-N0.0045 %
Stereo Line Input Impedance3,7k Ohm(s)
Stereo Line Input S/N Ratio116 dB
Stereo channel equalizer treble+/- 15 dB @ 12000 Hz
Stereo channel equalizer mids+/- 15 dB @ 2500 Hz
Stereo channel equalizer bass+/- 15 dB @ 80 Hz
Controls Stereo Line Input Channels2-band EQ (High,Low), 3-band EQ (High, Mid, Low), AUX 1 umschaltbar Pre/Post, AUX 2 (DFX) Post, Balance, Channel Volume, DFX/AUX 1, Gain, Low Cut

Main Section:

AUX / Effects Send Channels2
AUX / Effects Send Connectors6.3 mm TRS
Stereo AUX Return Channels1 x stereo
Stereo AUX Return Connectors6.3 mm TRS
Stereo Tape Out Channel1 x stereo
Stereo Tape Out Connectors2 x RCA (Cinch)
Stereo Tape In Channel1 x stereo
Stereo Tape In Connenctors2 x RCA (Cinch)
Balanced Stereo Main Out1
Balanced Stereo Main Out ConnectorsXLR
Balanced Stereo Main Out Impedance120 Ohm(s)
Max. Balanced Stereo Main Out Level23 dBu
Stereo Control Room Out1
Stereo Control Room Out Connectors6.3 mm TRS
Headphones ouput1
Headphones outputs6.3 mm TRS
Digital Effects ProcessorYes, 24-bit AD/DA Resolution
Number of Presets100
Footswitch Connector DFX Mute6.3 mm TRS
Main section controls2-track Assignment (Main, Contr. Room), 2-track In Volume, AUX 2 Send Volume, CTRL / Phones assignment (Main/Group 1-2), DFX Mute Schalter, DFX TO AUX Volume, DFX To Main Volume, Group 1-2 assignment to Main MIX, Group 1-2 Volume, Master Volume, PFL, Phantom Power, Power, presets, Stereo Return to AUX Volume, Stereo Return to MAIN Volume, Volume Control CTRL / Phones
IndicatorsDFX Peak, DFX TO MAIN, PFL, Phantom Power, Power
Operating voltage100 V AC - 240 V AC, 50 - 60 Hz
Width350 mm
Height98 mm
Depth440 mm
Weight4,3 kg
