de la in 60 de rate fixe.19" audio router, 5 stereo & 2 mic inputs, IR remote an RS485 control option
| Power supply: | 115/230 V AC, 50/60 Hz |
| Power consumption: | Max. 10 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via IEC (M) power supply cord with safety plug (provided) |
| Fuse: | 5 x 20 mm, T 0.5 A fuse replaceable |
| Frequency range: | 20 - 20000 Hz |
| S/N ratio: | >104 dB |
| THD: | 70 dB |
| Display type: | 2 x LCD display |
| Control elements: | Power switch, encoder, level control per channel, phantom power switch, mute control; source selector, low cut switch |
| Connections: | Input: stereo via 4 x stereo RCA Input: stereo via 2 x 6.3-mm-jack (bal.) Input: microphone via 2 x screw plug-in terminal Output: zones via 2 x screw plug-in terminal Antenna via 1 x SMA (F) mounting version RS 485 via 3 x RJ-45 (F) mounting version Mute function via screw plug-in terminal Emergency via screw plug-in terminal |
| Equalizer: | Master: 2 x 2-band tone control |
| Color: | Black |
| Housing design: | (19") 48.3 cm rack installation 1 U |
| Dimensions: | Width: 48.3 cm Depth: 25 cm Height: 4.4 cm |
| Weight: | 3.45 kg |
