de la in 60 de rate fixe.Aplicatii:
High-quality permanent installations in theatres, clubs, indoor sports arenas; an ideal combination for all Outline 'point source' systems (especially the EIDOS full-range series).
Multi-purpose subwoofers, suitable for high quality mobile applications.
Caracteristici:
Specificatii tehnice:
| FREQUENCY RESPONSE | (-10 dB) 32 Hz - 2.4 kHz (±3 dB) 42 Hz - 2 kHz |
|
| SUGGESTED CROSSOVER | max 150 Hz | |
| DISPERSION | Quasi-Omnidirectional | |
| IMPEDANCE (Ω) | Nom (min): 4 Ω (3 Ω @ 41 Hz) | |
| SENSITIVITY (dBSPL 1m, 1W, free-field) | 98 dB SPL | |
| POWER - WATTS | AES | Peak |
| 1200W | 4800W | |
| MAX SPL @ 1m, free-field (calculated) | RMS | Peak |
| 129 dB SPL | 135 dB SPL | |
| TRANSDUCERS & LOADING | LF 2 x 15" high-pass loaded woofers | |
| CONNECTORS | 1 x NL4 LF pin 1+ (pos); pin 1- (neg) |
|
| WEIGHT | Single unit | Shipping (1 unit) |
| 47.5 kg | 50 kg | |
| DIMENSIONS | Single unit | Shipping (1 unit) |
| H x W x D | 45 x 94 x 68 cm | 46 x 95 x 71 cm |
