| Nominal Diameter |
260 mm (10 in) |
| Rated Impedance |
8 Ohm |
| AES Power |
250 W |
| Program Power |
320 W |
| Peak Power |
650 W |
| Sensitivity |
100,5 dB |
| Frequency Range |
65 ÷ 6100 Hz |
| Power Compression @-10dB |
0,8 dB |
| Power Compression @-3dB |
1,9 dB |
| Power Compression @0dB |
2,9 dB |
| Max Recomm. Frequency |
3000 Hz |
| Recomm. Enclosure Volume |
10 ÷ 30 lt. (0,35 ÷ 1,06 cuft) |
| Minimum Impedance |
10,3 Ohm at 25°C |
| Max Peak To Peak Excursion |
18 mm (0,71 in) |
| Voice Coil Diameter |
51 mm (2 in) |
| Voice Coil Winding Material |
copper |
| Suspension |
double half roll, treated polycotton |
| Cone |
Curvilinear, treated paper |
| Fs |
70 Hz |
| Re |
5,1 Ohm |
| Sd |
0,035 sq.mt. (54,25 sq.in.) |
| Qms |
3,5 |
| Qes |
0,37 |
| Qts |
0,33 |
| Vas |
41 lt. (1,45 cuft) |
| Mms |
21 gr. (0,05 lb) |
| BL |
12 Tm |
| Linear Mathematical Xmax |
± 2,5 mm (± 0,10 in) |
| Le (1kHz) |
1,05 mH |
| Ref. Efficiency 1W@1m (half space) |
97,7 dB |
| Overall diameter |
260 mm (10,24 in) |
| N. of mounting holes |
8 |
| Mounting holes diameter |
7,15 mm (0,28 in) |
| Bolt circle diameter |
244,5 mm (9,63 in) |
| Front mount baffle cutout ø |
232 mm (9,13 in) |
| Rear mount baffle cutout ø |
232 mm (9,13 in) |
| Total depth |
121,5 mm (4,78 in) |
| Flange and gasket thickness |
14,5 mm (0,57 in) |
| Net weight |
4,7 kg (10,38 lb) |
| Shipping weight |
5,10 kg (11,26 lb) |
| CardBoard Packaging dimensions |
275 x 275 x 164 mm (10,83 x 10,83 x 6,46 in) |
|
