de la in 60 de rate fixe.Fresnel spotlight, dim to warm, 170 W warm white/amber LED, CRI >90, quiet, DMX
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 150 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug included |
| Power output: | P-Con (grey), mounting version |
| Lamp type: | LED lamp |
| LED type: | 1 x 170 W COB (chip-on-board) Dim to warm (homogenous color mix) |
| Flash rate: | 1.6 - 12 Hz |
| Equipment: | Zoom motor driven |
| DMX channels: | 2; 6; 7 |
| DMX input: | 1 x 3-pin XLR (M) mounting version 1 x 5-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version 1 x 5-pin XLR (F) mounting version |
| Cooling: | Temperature-controlled fan |
| Control: | RDM; DMX |
| Fixtures available for: | Light´J; Light Captain |
| Projection: | Flicker-free |
| PWM frequency: | 3600 Hz |
| Beam angle: | 8° - 55° |
| Beam angle (1/2 peak): | 8 - 39° |
| Beam angle (1/10 peak): | 12 - 55° |
| Color rendering index (CRI): | 96 Ra |
| Luminous flux: | 5093 lm |
| Housing color: | Black |
| Attachment system: | Mounting bracket |
| Display type: | LCD display |
| Transport aid: | Rubber feet |
| Material: | Aluminum casting; metal |
| Slot for spot length: | 20 cm x 20 cm |
| Dimensions: | Length: 45.7 cm Width: 33.6 cm Height: 39.8 cm |
| Weight: | 9.40 kg |
| Noise classification: | Class 2 (slight noise) |
| Energy efficiency class (A - G): | G |
| EPREL-Nr: | 1243870 |
| Mounting bracket | |
| Diameter mounting holes: | 5 x Ø10mm |
| Material: | Aluminum casting, 6.5 mm |
| Power cord | |
| Cable construction: | 3 x 1.5 mm² H05VV-F |
| Cable length: | Approx. 1.3 m |
| Barndoor | |
| Material: | Aluminum, 1.5 mm; metal, 1 mm |
| Ring diameter: | Outside: 198 mm Inside: 220 mm |
| Dimensions: | Width: 50.5 cm Depth: 4.2 cm Height: 50.5 cm |
| Filter frame | |
| Material: | Aluminum, 1 mm |
| Dimensions: | Width: 22.5 cm Height: 22.5 cm Diameter: Ø 18 cm |
