Surface light with 360 cold white (CW)LEDs and DMX
mounting bracket
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 130 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Cable construction: | 3 x 1.5 mm² H05VV-F |
| Cable length: | 1.2 m |
| Power output: | 1 x IEC connector (F) mounting version |
| Fuse: | 5 x 20 mm, T 1.5 A fuse replaceable |
| Lamp type: | LED lamp |
| Lamp specification: | Dimmable |
| LED type: | 360 x 0.5 W SMD 2835 cold white (CW) |
| Equipment: | Frost filter |
| DMX channels: | 3 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Cooling: | Passive convection cooling |
| Control: | Quick select potentiometer for brightness; DMX; master/slave function |
| Fixtures available for: | Light´J; LED PC-Control 512; Light Captain; Colorchief |
| Projection: | Flicker-free |
| DMX fail mode: | Blackout |
| Beam angle: | 120° |
| Beam angle (1/2 peak): | 120° |
| Color temperature: | 6000K |
| Color rendering index (CRI): | 94 Ra |
| Illuminance in Lux (lx): | Cold white (CW) 1m: 3532 lx, 3m: 373 lx, 6m: 96 lx |
| Lamp life: | 50000 h |
| Luminous flux: | 9937 lm |
| Housing color: | Black |
| Attachment system: | Mounting bracket |
| Display type: | LCD display |
| Carrying handle: | 1 pc/pcs |
| Diameter mounting holes: | 3 x Ø11mm |
| Material: | Metal, painted |
| Dimensions: | Width: 57 cm Depth: 12 cm Height: 31 cm |
| Weight: | 6.10 kg |
| Noise classification: | Class 0 (no noise at all) |
| Energy efficiency class (A - G): | F |
| EPREL-Nr: | 1056097 |
| Spotlight | |
| Material thickness: | 0.12 mm |
| Frost filter | |
| Material: | Plastic |
