DMX splitter for splitting one DMX input signal to 4 DMX outputs
Input and outputs galvanically isolated
Input and outputs with a set of respective power supply and internal fuse
Switchable termination resistor
Each DMX output with independent driver and status indicator
Power supply:
230 V AC, 50 Hz
Power consumption:
20 W
Protection class:
Protection class I
Power connection:
Fixed power supply cord with safety plug
Cable construction:
3 x 0.75 mm² H05VV-F
DMX input:
1 x 3-pin XLR (M) mounting version 1 x 5-pin XLR (M) mounting version
DMX output:
4 x 3-pin XLR (F) mounting version separate (galvanic) with independent driver and status indicator 4 x 5-pin XLR (F) mounting version separate (galvanic) with independent driver and status indicator 1 x 5-pin XLR (F) mounting version Bypass 1 x 3-pin XLR (F) mounting version Bypass
Housing color:
Black
Attachment system:
2x Ø 10mm
Control elements:
Bypass/terminating resistor switch
Material:
Steel
Dimensions:
Width: 32.5 cm Depth: 19 cm Height: 8 cm
Weight:
2.55 kg
