The innovative DAD’s D-class DP amplifiers series uses an advanced design that drastically reduces the weight and dissipation of heat. Efficiency between energy consumption and output available the power is 95%. The amplifiers of DP series are designed with a new high audio resolution D-class typology.
These revolutionary amplifier series provide a superior quality sound and an unequalled reliability. Protection circuits allow greater efficiency under difficult loads and power conditions. In other words, an amplifier that doesn’t hurt nor your budget nor your back!
Features:With a single channel power of 1000/1750 W 8/4 Ohm, new DP4000 Class D is the best solution for sound applications that require a multi-channel amplifier of average power with a great sound at affordable price.
Thanks to Universal technology, regulated switch mode with PFC (Power Factor Correction) it allows performances with supply voltages from 90V to 260V.
AMPLIFIERChannels:
2
Circuit class:
digital
OUTPUTSingle channel power:
1000/1750
W
8/4 Ohm
Bridge mode power:
3500
W
8 Ohm
AUDIO SPECIFICATIONSFrequency responce:
20 - 20000
Hz @ 8 Ohm
(±0.5 dB)
THD+N:
<0.15
%
Slew rate:
>10
V/μs @ 8Ω
Damping factor:
>500
Input impedance:
10
kΩ
Signal/Noise rate:
>100
dB
PROTECTIONSOutput:
Soft-start, short circuit, DC, overheat
Input:
Clip/limit, progressive volume
INPUT/OUTPUT CONNECTORSInput signal:
XLR in/out
Output signal:
2 x 4 pole, binding post
Power connection:
VDE
PHYSICALCooling:
active, silent operation
Dimensions (WxHxD):
483x89x305
mm
Rack unit:
2
Weight:
7.3
kg
