CIRA506/W - QuickFit™ 2-way 5 1/4" ceiling speaker with TwistFix™ grill - White version, 8Ω & 6 Watt @ 100V

Audac
cod produs: CIRA506/W
La comanda
249.42 Lei
*pretul include TVA
Cumpara
+-

Descrierea Produsului

Designed to offer the best value for money ratio. The CIRA series are coaxial 2-way ceiling speakers featuring exceptional intelligibility and musical performance. The TwistFix™ borderless grill design offers easy but solid assembly and a completely seamless transition from grill to ceiling. This results in a perfect blend in to its environment. The QuickFit™ installation system combined with FastCon™ connector offers lifetime stability and great installers convenience.

The CIRA5 features a 5 ¼” driver using polypropylene cone material, combined with a 1” Mylar tweeter fitted with a phase plug for excellent off axis performance. The selected materials guarantee a low distortion performance with smooth and flat frequency response. A continuous power handling of 30 Watt (RMS) and maximum power handling of 60 watt is achieved, while fitted with a multi-tapping 100V line transformer with tappings for 6W, 3W, 1.5W and an 8 Ohm or 16 Ohm bypass connection.

System specifications
Max. Power60 W
RMS Power30 W
Sound Pressure (Max. W/1m)@ 100 V102 dB
Sensitivity (1W/1m)87 dB
FrequencyResponse (± 3 dB)60 Hz - 20 kHz
Speaker type2-way coaxial
Impedance16 Ω (CIRA530D)
Impedance8 Ω (CIRA506 & CIRA524)
FrequencyRange (-10 dB)45 Hz - 20 kHz
DispersionConical145°
ConnectorsMulti-tap Fast-con™ connections
DriversLF5 ¼" Woofer
DriversHF1”
Line Transformer Tappings16 W - 1667 Ω (CIRA506)
Line Transformer Tappings124 W - 417 Ω (CIRA524)
Line Transformer Tappings23 W - 3333 Ω (CIRA506)
Line Transformer Tappings212 W - 833 Ω (CIRA524)
Line Transformer Tappings31.5 W - 6667 Ω (CIRA506)
Line Transformer Tappings36 W - 1667 Ω (CIRA524)
Product features
Cut-out measurement170 mm (Ø)
Dimensions193 x 83 mm (Ø x D)
Weight1.10 kg (CIRA506)
Weight1.15 kg (CIRA524)
Weight1.05 kg (CIRA530D)
ConstructionABS
Front finishTwistFix™Borderless finely perforated steel grill
MountingQuick-Fit™ mounting system
ColoursWhite (RAL9003) (CIRA506/W, CIRA524/W & CIRA530D/W)
Built-in depth83 mm (CIRA524)
Built-in depth75 mm (CIRA506 & CIRA530D)
Dimensions193 mm (Ø)
