4-point trussing tower complete set
ALUTRUSS Tower System I
4-point trussing tower complete set
ALUTRUSS Tower Outrigger, long
| Corner angle: | 60° |
| Weight: | 135.30 kg |
| ALUTRUSS Tower System I | |
| Setup: | Easy installation |
| Maximum carrying capacity: | 1000 kg |
| Height: | Maximum: 700 cm |
| Trusspipe: | 50 mm x 3 mm |
| Welding technique: | TIG-welding |
| Welding material: | AlMg 5 |
| Alloy: | EN-AW 6082 T6 (AlSi1Mg) |
| Material: | Aluminum; steel |
| Color: | Alu colored |
| Strut diameter x thickness: | 20 x 2mm |
| Dimensions: | Width: 62 cm Depth: 62 cm Height: 107 cm |
| Weight: | 92.50 kg |
| ALUTRUSS Tower Outrigger, long | |
| Trusspipe: | 50 mm x 2 mm |
| Welding technique: | TIG-welding |
| Welding material: | AlMg 5 |
| Material: | Steel; aluminum |
| Color: | Alu colored; black/yellow |
| Dimensions: | Length: 117 cm Width: 3.5 cm Height: 34 cm |
| Weight: | 10.70 kg |
