Compact residual current circuit breaker.
Features:Code: MDC 60.
No. of poles: 1P+N.
No. modules: 2.
Rated current: 32 A.
Rated residual operating current: 30 mA.
Type A.
Curve C.
Rated voltage (EN/IEC 61009-1, 61009-2-1): 230/240 V.
Standard: IEC/EN 61009-1, IEC/EN 61009-2-1.
Rated frequency: 50/60 Hz.
Breaking capacity EN 61009-1 230V (Icn): 6000 A.
Breaking capacity EN 61009-1 (Ics): 1 x Icn.
Breaking capacity EN 60947-2 230V (Icu): 7.5 kA.
Breaking capacity EN 60947-2 (Ics): 100% Icu.
Insulation voltage: 500 V.
Level of immunity (8/20 μs): 250 A.
Rated impulse withstand voltage: 4 kV.
Overvoltage category: III.
Electrical endurance: 10000.
Mechanical endurance: 20.000.
Section rigid cable: <=1x35 - <=2x16 - <=1x16+2x10 mm²
Section flexible cable: <=1x35 - <=2x16 - <=1x16+2x10 mm².
Double connection: Yes (only down stream).
Rated tightening torque: 2 Nm.
Operating temperature: -25 +40 °C.
Stocking temperature: -40 +70 °C.
Auxiliaries compatibility: Yes.
ReStart compatibility: Yes.
Assembly position: Any.
