The new Audio 3-stage CLASS-H SMPS amplifiers incorporate all the features to meet all your needs, whether you’re starting a P.A. amplifier project from scratch or just need to upgrade your present sound reinforcement equipment. In the amps, you’ll find 2 and 4 channel models, all offering high power levels at low distortion in the range 1.5 to 6 kW, yet weighing around 8.6 kg and only 30 cm deep.
Product type | Power Amplifiers |
Type | PA Power Amplifiers |
Rated ouput power (1kHz @ 2 Ohms) | 2 x 880 W |
Rated ouput power (1kHz @ 4 Ohms) | 2 x 575 W |
Rated ouput power (1kHz @ 8 Ohms) | 2 x 325 W |
Rated ouput power (1kHz @ 4 Ohms, bridged) | 1760 W |
Rated ouput power (1kHz @ 8 Ohms, bridged) | 1150 W |
Output circuitry | Class H |
Frequency response | 20 - 20000 Hz |
Total Harmonic Distortion (THD) | < 0.05 % |
Signal-to-noise ratio | 112 dB |
Damping factor | > 500 |
Crosstalk | >75 dB |
Gain | 26 / 32 / 38 dB |
Input sensitivity | 2.6 / 1.3 / 0.6 V |
Protection circuits | DC, ICL (Intelligent Clip Limiting), mute when turning on, Open or mismatched loads, power supply overload, short circuit, soft start, thermal protection |
Controls | bridge/stereo mode selector, dual/link switch, gain, mains switch (on/off), volume |
Indicators | ICL (Intelligent Clip Limiting), PMS, Signal, temperature |
Loudspeaker outputs | 2 |
Speaker output connections | Speakon |
Cooling | 2 fans, temperature controlled |
Operating voltage | Switching power supply, 220 V AC - 240 V AC, 50-60 Hz |
Width | 483 mm |
Height | 89 mm |
Depth | 310 mm |
Weight | 8 kg |
