Mixer Allen & Heath ZED 12FX

Allen & Heath
cod produs: ZED12FX
La comanda
2595.69 Lei
*pretul include TVA
Cumpara
+-

Descrierea Produsului

Completand seria ZED existenta, ZED FX a fost dezvoltat in jurul unui chipset FX pentru noile modele. Inginerii DSP au muncit din greu, lucrand si rafinand frumoasele algoritme de reverb. Efectele nu sunt disponibile in niciun alt loc, aceasta calitate fiind gasita doar in ZED FX. 16 efecte de delay esentiale sunt adaugate in setul deja plin de trasaturi. Mixerul este ideal pentru grupuri mici ce nu vor sa care dupa ei unitati de efecte dar care doresc o calitate exceptionala a efectelor la spectacole si pe inregistrari.

6 mono channels

16 internal time-delay effects

Neutrik mic XLR

Neutrik 1/4 inch jacks

Channel insert

Super wide gain "DuoPre" mic line input

3 band EQ with MusiQ

4 auxes

Illuminated mute

Sound image pan

Illuminated PFL & peak warning indicator

ALPS 100mm faders

4 stereo channels with 2-band EQ and inputs for extra sources

Stereo returns & playback

All inputs with level control

12 bar meters

Mono/stereo function on auxes 1&2

Monitor output section

Alt stereo output source

Configurable USB stereo audio in/out

Cakewalk SONAR LE bundled with mixer

Rack ears available

USB audio flexibility
Getting audio to and from a computer easily is now a common requirement for live sound and music production. The way this has been implemented on ZED is super-flexible and super-easy! No longer do you need to fiddle around the back of your PC to get to the soundcard inputs, only to find that the levels are all wrong and noisy. Just plug in a USB lead to your ZED, select the USB routing on the mixer and the device on your computer and that's it! CD quality audio to and from your PC or Mac. Switches and connection through jack socket terminals provide different send/return configurations:-
Send options:
1) Main Mix Left + Right (Post master Level)
2) Aux + FX bus (Aux is a pre-fade send, FX is a post-fade send)
3) Record Bus Left + Right (Separate stereo bus to Main Mix)
Return Options:
1) To Playback input (through jack socket break contacts)
2) To Stereo 2 channel (through jack socket break contacts)
MusiQ
ZED-12FX features a responsive 3-band, swept mid frequency EQ design which utilises MusiQ – with optimised slope (or Q factor) for equalising individual instruments.
DuoPre™
Based on the proven pre-amps from the hugely successful PA series, ZED-12FX has DuoPre pre-amps, which use a two stage design, with carefully controlled amounts of gain in each stage. When amplifying the signal from the XLR input, the gain range is huge - 69dB of range to be exact - and is very evenly distributed around the gain control, meaning better control of signal level. Most of the gain comes from the first stage, so unwanted noise is kept to a minimum. Line level signals are simply plugged into the second stage of the pre-amp by using the line input jack socket, which has the great advantage of less noise when using the line input and also matching to a
higher input impedance.
ZED-FX
ZED-12FX has an essential selection of 16 time-delay effects, designed for small groups who don"t want to carry around an effects unit with their gear but who
still want great quality FX at their gigs and on their recordings. Our DSP engineers worked hard, crafting and refining beautiful reverb algorithms to enhance every performance. These effects are available nowhere else at this price point – this quality and integration is only available from the ZED-FX. ZED effects are easily controlled using 3 buttons with 9 display LEDs. For example, the ideal delay time can be quickly tapped-in, or the perfect amount of reverb on the lead vocal can be dialled-in. There is one-stop navigation and editing – in fact, it"s just as easy as using effects pedals. To alter effects parameters, the TAP button is held down and the up/down buttons pressed to adjust the specific parameter for that effect, for example, the decay length on PLATE, or the depth on CHORUS.
SONAR LE – Provided Free!
We"ve included Cakewalk SONAR LE with ZED-12FX so you can immediately start to use it to create your own music – just add a PC and it couldn"t be easier to get going. You"ll be able to record from your ZED mixer, create tracks and arrange songs, then play back to ZED via the USB port. You can use SONAR LE and your ZED mixer together in many ways – e.g. straightforward recording of a stereo mix, recording tracks individually to build up a song, or using the USB port and software as an effects loop.

Key Features

Powered by SONAR 8.5

32 audio tracks

64 MIDI tracks

8 simultaneous inputs and outputs

24-bit/96kHz audio quality

24 simultaneous effects

8 simultaneous virtual instruments

Specificatiile Produsului

  • Intrare USB Da
  • Numar canale 12 canale
  • Tip mixer audio Mixer scena (live), Mixer instalatii
