Boxa pasiva ESD25 - KV2 Audio

KV2 Audio
cod produs: KVV 987 368
La comanda
5233.91 Lei
*pretul include TVA
Cumpara
+-

Descrierea Produsului

2-Way Full-Range Compact Low Profile Passive Loudspeaker

The ESD25 is a very high quality 2-way full-range compact low profile passive loudspeaker with increased lower bass extension than the smaller ESD5. Its opposing driver design assists with pattern control of the low mid frequencies reducing reflections in reverberant spaces and improving intelligability. Delivering exceptional clarity for speech and program reproduction the ESD25 is ideal for under balcony or front stage fill applications in theatres and performing arts spaces where transparent supplementation of the main system is required. As with the already widely acclaimed ESD5 the ESD25 is shaped to fit discreetly into these applications and comes with its on integral bracket for quick installation.

 Professional, Baltic birch construction with wear resistant polymer coating
  • 120dB sustained output, 123dB peak with very high dynamic range
  • Compact cabinet design allows for use as front fill, in-fill or under balcony applications
  • Wide dispersion 90° H x 90° V horn
  • Revolutionary new passive delay line
  • 1/1.3" (34,4 mm) diaphragm compression driver with complex geometry phase plug for higher output, exceptionally low distortion, extended frequency response and ferrite magnetic motor structure
  • Two 5" woofers with Low Inductance Lightweight voice coil technology and motor structure dramatically increases force and lowers distortion
  • Proprietary design for simplified mounting integrates two M10 suspension points
  • Horizontal bracket (KVV 987 375) is included with the product.

    Applications

    Specifically designed as a discreet passive loudspeaker for reproduction of recorded music and speech

    • Suitable in fixed installations as a full range speaker or as a system with accompanying subwoofers
    • Excellent peripheral reinforcement for main KV2 systems
    • Fill-in speaker
    • Monitoring
    • Ceiling or under balcony mounting

    System Acoustic Performance

    Max SPL Long-term 120dB
    Max SPL Peak 123dB
    -3dB Response 120Hz to 22kHz
    Crossover Point 3.0kHz

    High Frequency Section

    Acoustic Design Horn Loaded
    High Horn Coverage Horizontal / Vertical 90° x 90°
    Throat Exit Diameter / Diaphragm Size 1 / 1.3"
    Diaphragm Material Titanium
    Magnet Type Ferrite
    Protection RMS Limiter

    Low Frequency Section

    Acoustic Design Closed box
    Number of Drivers 2
    Woofer Size / Voice Coil Diameter / Design 5" / 1.75"
    Magnet Type Ferrite
    Diaphragm Material Epoxy Reinforced Cellulose
    Protection RMS Limiter

    Speaker Input

    Speaker Input 2x Neutrik Speakon®, Terminal Block

    Cabinet

    Cabinet Material Baltic birch
    Color Orange peeled Matt Black or any RAL

    Physical Dimensions

    Height 150 mm (5,9")
    Width 442 mm (17.4”)
    Depth 260 mm (10.24”)
    Weight 9.6 kg (21.2lbs)
